Window rebate vents FFL Type 34 RF
Contents: 2 vents per sales unit, including gasket
Product information " Window rebate vents FFL Type 34 RF"
The Regel-air ventilation system ® FFL Type 34
Our Regel-air ventilation system FFL Type 34 is an automatic, self-regulating window rebate vents. It is made of PVC and features automatic airflow limitation. This makes it very easy to prevent damp and mould damage. The pressure differential present in the building is utilised to ensure automatic air exchange and the supply of fresh air to all rooms. Fresh outside air simply flows into the interior of the room through the Regel-air ® FFL window rebate vents.
To prevent draughts, the ventilation flaps automatically close when wind pressure increases. Controlled air exchange is guaranteed when the system is installed correctly.
The FFL ventilation systems operate purely mechanically. No power supply is required for this energy-efficient ventilation.
We recommend fitting every room with Regel-air ® ventilation systems. This ensures that the entire flat is reliably ventilated.
Suitable for the following window systems:
Gealan: Kubus, Kontur
Hapa: Therm5plus MD, Therm5plus premium MD, Therm7plus MD
Hoco: H 240 MD, H 260 MD, HX 80 MD, Classic C 80, Classic C 80 S, Style S 80, Style S 80 S, Prestige P95, Prestige P95 S, Prestige Plus P95+
Iller Plastic: KLASSIK 74, EXKLUSIV 80
Rehau: ARTEVO
| Achievable air flow rates in the range of 2 to 8 Pa: | Depending on the vent combination (at least 1 pair), 3.0 to 7.8 m³/h |
|---|---|
| Air control: | Automatic, flow-dependent |
| Classification in accordance with DIN EN 1026 and DIN EN 12207: | Class 3 |
| Contents of the package: | Supplied with all the necessary seals and fitting materials |
| Installation: | Retrofitting, factory-fitted |
| Noise protection achievable (depending on the type of glazing): | Up to 42 dB (up to Class 4) |
| Permissible limit value in accordance with DIN EN 12207-4.4: | At 100 Pa: 9.00 m³/hm² |
| Resistance to driving rain in accordance with DIN 12208: | No water ingress up to a maximum test pressure of 600 Pa |
| Vents per sales unit: | 2 pieces |
| Wide single fans: | 125 mm |
| Width: 1 pair of window rebate vents FFL (=2 fans): | 250 mm |
| Window material: | PVC window |
